High Frequency Piezoelectric Resonant Nanochannel for Bio-Sensing Applications in Liquid Environment
Penn collection
Degree type
Discipline
Subject
Engineering
Funder
Grant number
License
Copyright date
Distributor
Related resources
Contributor
Abstract
This paper reports on the first demonstration of a 457 MHz AlN Piezolectric Resonant Nanochannel (PRN) for biosensing applications in liquid environment. A novel process consisting of 7 lithographic steps was developed to fabricate the PRN. The new resonant device shows an unchanged value of the electromechanical coupling, kt 2 (about 0.8 %), whether the channel is filled with air or water and a quality factor, Q, in liquid of approximately 170. The value of kt 2 and Q are respectively about 2.7 and 2 times the ones recorded for conventional laterally vibrating AlN Contour Mode Resonant Sensors (CMR-Ss) submerged in water. Overall, these results translate in a ~ 5 fold enhancement in the figure of merit (kt 2 - Q product) of the resonant device when operated in liquid and simultaneously permit the efficient delivery of ultra-low concentrations of fluid samples directly on the surface of the sensor.
