Ultra-Thin-Film AlN Contour-Mode Resonators for Sensing Applications
Acoustics, Dynamics, and Controls
Electrical and Electronics
Electronic Devices and Semiconductor Manufacturing
Nanoscience and Nanotechnology
This paper reports on the design and experimental verification of a new class of ultra-thin-film (250 nm) aluminum nitride (AlN) microelectromechanical system (MEMS) contour mode resonators (CMRs) suitable for the fabrication of ultra-sensitive gravimetric sensors. The device thickness was opportunely scaled in order to increase the mass sensitivity, while keeping a constant frequency of operation. In this first demonstration the resonance frequency of the device was set to 178 MHz and a mass sensitivity as high as 38.96 KHz⋅μm2/fg was attained. This device demonstrates the unique capability of the CMR-S technology to decouple resonance frequency from mass sensitivity.
