High-resolution characterization of defects in oxide thin films

Loading...
Thumbnail Image
Penn collection
Departmental Papers (MSE)
Degree type
Discipline
Subject
SCANNING CAPACITANCE MICROSCOPY
SPREADING RESISTANCE MICROSCOPY
SPATIAL-RESOLUTION
SILICON
SI
atomic force microscopy
dielectric thin films
flaw detection
leakage currents
Funder
Grant number
License
Copyright date
Distributor
Related resources
Contributor
Abstract

Nanometer sized defects in thin HfOx films are detected by atomic force microscopy facilitated leakage current measurements. Differences in the electrical properties of individual defects were distinguished. The effects of two mechanisms that localize the tip-sample interaction and increase spatial resolution were calculated. The expected increase in tip-sample current due to stress induced phase transformations and band gap narrowing has been calculated, and a behavior diagram is presented that shows the pressure necessary to generate a detectable current increase as a function of tip radius.

Advisor
Date Range for Data Collection (Start Date)
Date Range for Data Collection (End Date)
Digital Object Identifier
Series name and number
Publication date
2008-11-03
Journal title
Volume number
Issue number
Publisher
Publisher DOI
Journal Issue
Comments
Copyright (year) American Institute of Physics. This article may be downloaded for personal use only. Any other use requires prior permission of the author and the American Institute of Physics. Reprinted from: High-resolution characterization of defects in oxide thin films Maxim N. Nikiforov, Matthew J. Brukman, and Dawn A. Bonnell, Appl. Phys. Lett. 93, 182101 (2008), DOI:10.1063/1.2982082 Publisher URL: http://link.aip.org/link/?APPLAB/93/182101/1
