Microscale inverse acoustic band gap structure in aluminum nitride

Loading...
Thumbnail Image
Penn collection
Departmental Papers (ESE)
Degree type
Discipline
Subject
acoustic wave velocity
aluminium compounds
energy gap
III-V semiconductors
lattice constants
semiconductor thin films
Funder
Grant number
License
Copyright date
Distributor
Related resources
Contributor
Abstract

This work presents the design and demonstration of a microscale inverse acoustic band gap (IABG) structure in aluminum nitride (AlN) with a frequency stop band for bulk acoustic waves in the very high frequency range. Conversely to conventional microscale acoustic band gaps, the IABG is formed by a two-dimensional periodic array of unit cells consisting of a high acoustic velocity material cylinder surrounded by a low acoustic velocity medium. The periodic arrangement of the IABG array induces scattering of incident acoustic waves and generates a stop band, whose center frequency is primarily determined by the lattice constant of the unit cell and whose bandwidth depends on the cylinder radius, the film thickness, and the size of the tethers that support the cylinder. A wide band gap (>13% of the center frequency) is formed by the IABG even when thin AlN films are used. The experimental response of an IABG structure having a unit cell of 8.6 µm and an AlN film thickness of 2 µm confirms the existence of a frequency band gap between 185 MHz and 240 MHz.

Advisor
Date Range for Data Collection (Start Date)
Date Range for Data Collection (End Date)
Digital Object Identifier
Series name and number
Publication date
2009-09-02
Journal title
Volume number
Issue number
Publisher
Publisher DOI
Journal Issue
Comments
Copyright 2009 American Institute of Physics. This article may be downloaded for personal use only. Any other use requires prior permission of the author and the American Institute of Physics. Reprinted from: Microscale inverse acoustic band gap structure in aluminum nitride Nai-Kuei Kuo, Chengjie Zuo, and Gianluca Piazza, Appl. Phys. Lett. 95, 093501 (2009), DOI:10.1063/1.3213345 Publisher URL: http://link.aip.org/link/?APPLAB/95/093501/1
