HALO: Haptic Alerts for Low-hanging Obstacles in White Cane Navigation

Thumbnail Image
Penn collection
Departmental Papers (MEAM)
General Robotics, Automation, Sensing and Perception Laboratory
Degree type
Grant number
Copyright date
Related resources

White canes give the visually impaired the freedom to travel independently in unknown environments, but they cannot warn the user of overhead hazards such as tree branches. This paper presents the development and evaluation of a device that provides haptic cues to warn a visually impaired user of low-hanging obstacles during white cane navigation. The Haptic Alerts for Low-hanging Obstacles (HALO) system is a portable and affordable attachment to traditional white canes. By pairing distance data acquired from an ultrasonic range sensor with vibration feedback delivered by an eccentric mass motor, the device aims to alert users of low-hanging obstacles without interfering with the standard functionality of a white cane. We conducted a preliminary validation study wherein twelve blindfolded subjects navigated a custom obstacle course with and without vibration alerts from HALO. The results showed that this new device is intuitive and highly effective at enabling the user to safely navigate around low-hanging obstacles.

Date of presentation
Conference name
Departmental Papers (MEAM)
Conference dates
Conference location
Date Range for Data Collection (Start Date)
Date Range for Data Collection (End Date)
Digital Object Identifier
Series name and number
Volume number
Issue number
Publisher DOI
Journal Issue
Y. Wang, K. J. Kuchenbecker. HALO: Haptic Alerts for Low-hanging Obstacles in white cane navigation. In Proceedings, IEEE Haptics Symposium, 527-532, March 2012. doi: http://dx.doi.org/10.1109/HAPTIC.2012.6183842 © 2012 IEEE. Personal use of this material is permitted. Permission from IEEE must be obtained for all other uses, in any current or future media, including reprinting/republishing this material for advertising or promotional purposes, creating new collective works, for resale or redistribution to servers or lists, or reuse of any copyrighted component of this work in other works.
Recommended citation
