Resistance Fluctuations in Randomly Diluted Networks

Thumbnail Image
Penn collection
Department of Physics Papers
Degree type
Grant number
Copyright date
Related resources
Blumenfeld, Raphael
Meir, Yigal
Aharony, Amnon

The resistance R(x,x’) between two connected terminals in a randomly diluted resistor network is studied on a d-dimensional hypercubic lattice at the percolation threshold pc. When each individual resistor has a small random component of resistance, R(x,x’) becomes a random variable with an associated probability distribution, which contains information on the distribution of currents in the individual resistors. The noise measured between the terminals may be characterized by the cumulants Mq(x,x’) of R(x,x’). When averaged over configurations of clusters, M¯q(x,x’)~‖x-x’‖ψ̃(q). We construct low-concentration series for the generalized resistive susceptibility, χ(q), associated with M¯q, from which the critical exponents ψ̃(q) are obtained. We prove that ψ̃(q) is a convex monotonically decreasing function of q, which has the special values ψ̃(0)=DB, ψ̃(1)=ζ̃R, and ψ̃(∞)=1/ν. (DB is the fractal dimension of the backbone, ζ̃R is the usual scaling exponent for the average resistance, and ν is the correlation-length exponent.) Using the convexity property and the accepted values of these three exponents, we construct two approximant functions for ψ(q)=ψ̃(q)ν, both of which agree with the series results for all q>1 and with existing numerical simulations. These approximants enabled us to obtain explicit approximate forms for the multifractal functions α(q) and f(q) which, for a given q, characterize the scaling with size of the dominant value of the current and the number of bonds having this current. This scaling description fails for sufficiently large negative q, when the dominant (small) current decreases exponentially with size. In this case χ(q) diverges at a lower threshold p*(q), which vanishes as q→-∞.

Date Range for Data Collection (Start Date)
Date Range for Data Collection (End Date)
Digital Object Identifier
Series name and number
Publication date
Journal title
Physical Review B
Volume number
Issue number
Publisher DOI
Journal Issue
Recommended citation
